HFM® - High-Speed FAKRA-Mini

Following the revision of the IEC 61169-24 interface standard in response to the increasing performance demands of the broadcast television sector, Rosenberger has fundamentally revised its F-interface calibration elements. The considerably improved characteristics include an extended frequency range, from DC to 4 GHz up to DC to 6 GHz, and a doubling of mating cycles from 500 to 1000. The new 6 GHz-spectrum F series from Rosenberger comprises calibration adaptors, calibration loads, opens, shorts and loads. A new “full range” calibration adaptor is also available, addressing the extremely wide male connector pin tolerances of 0.64 mm to 1.13 mm.

Rosenberger’s new RPC-1.35* precision connector series meets the growing demand for precision, high-performance RF-connections up to 90 GHz. The range addresses the expanding market for 5G, industrial sensors in the E-Band, millimeter wave sensors for self-driving vehicles, WLAN IEEE 802.11ax and 802.11ay. RPC-1.35 connectors offer a highly robust mechanical design, minimum 3000 mating cycles, high connector repeatability, and maximum return loss values – ideal for ensuring RF measurements in the E-Band without delays. The product portfolio covers semi-rigid and flexible cable assemblies, PCB connectors, test PCBs, cable connectors, in-series and inter-series adaptors, test ports, floating and waveguide-to-coaxial adaptors as well as gauge and calibration kits. *A working group, comprising PTB (Physikalisch Technische Bundesanstalt), Rosenberger, Rohde & Schwarz and Spinner, designed the new 1.35 mm connector to close the gap between 1.85 mm and 1.00 mm connectors. The interface standardization is in progress.

Constantly increasing bandwidth requirements in all areas of communication and computing are placing ever greater demands on networking I/O equipment. Current edge-mount copper or fiber interfaces are at their limits even over the short distances on the PCB. Embedded parallel optics have become the solution of choice to meet these demands. High-performance routers, switches and computers have already been utilizing this technology for a decade. Parallel optic solutions are currently used in a wide range of applications: in links between nodes of supercomputers, switches in international Internet gateways as well as in data centers and central offices. Embedded opto-electrical modules and optical engines utilize parallel-optics transmitter and receiver arrays. For optimum signal integrity, thermal management, I/O consolidation and EMI/ESD, the opto-electrical modules are directly mounted close to the processors at the PCB. Parallel-optic links can complement electronic signalling in parallel lanes such as XAUI and PCIe. Using PRIZM® Light Turn®, it is possible to implement a passive plug connection between the opto-electrical modules and the fiber optic network.
