Single-sided pre-assembled LAN cabling system

Rosenberger RPC-1.85 precision connectors – with 50 Ω impedance and 1.85 mm outer conductor diameter – are designed for test & measurement applications up to 70 GHz. Delivering outstanding reliability and repeatability performance they are intermateable with common 1.85 mm series and V connectors as well as with RPC-2.40 connectors. This comprehensive product range is suitable for semi-rigid cables and microwave components and includes cable, panel and PCB connectors, adaptors and test & measurement accessories – including RPC-1.85 calibration kits, cables assemblies, measurement equipment, attenuators, sliding loads and airlines.

The Rosenberger HVR®300 connector system not only provides a maximum current carrying capacity of 320 A, it takes up minimal space. It features a 2-pole angled coupler for shielded cables and a cable cross section of 70 mm² along with the corresponding header. A cross section of 50 mm² is available on request. The lever locking mechanism is secured with an additional slider (CPA – Connector Position Assurance) to prevent accidental unmating.

The Rosenberger FTTA/PTTA Connectivity Boxes are available in standard and tailor-made designs and configurations, in low or high volumes, to meet OEM or Network Operator requirements as to efficient, reliable and easy-to-deploy connectivity boxes. Rosenberger connectivity boxes, designed and produced in-house at Rosenberger in Germany, provide the best workmanship and highest quality to ensure a long and smooth operation even in the most harsh environments.
