HVR®300

Rosenberger provides a variety of snap-in D-Sub coaxial and power inserts for fast, reliable mixed card edge chassis. Their small dimensions allow high packing densities as well as easy connection. A combination including power connectors is also available on request. D-Sub Coax Inserts and cable connectors 50 Ω are designed for use in mixed card edge connections in accordance to D-Sub. The maximum frequency is approximately 2 GHz. Available on request. Power Inserts meet the requirements of DIN 41626-T1 and are designed for use in mixed card edge connections in accordance to DIN 41612 or D-Sub. Contact current 10 A, 20 A, 30 A, 40 A. Available on request.

Rosenberger RPC-1.00 precision connectors – with 50 Ω impedance and 1.00 mm outer diameter – can be used for challenging test & measurement applications up to 110 GHz. They are characterized by excellent technical data over the full frequency range, meet the highest levels of reliability and repeatability of performance, and are intermateable with common 1.00 mm connectors. The standard portfolio covers flexible and semi-rigid cable assemblies, adaptors and PCB connectors. Waveguide-to-coaxial adaptors and gauge kits are also available. Customer-specific cable assembly solutions with or without armouring available on request.

Rosenberger RPC-SP 50 Ω precision connectors are designed for applications up to 22 GHz where quick and reliable interconnects are essential. Intermateable with OSP and BMA connectors, the floating construction allows compensation for axial and radial misalignment while the innovative blind mate self-finding mechanism ensures fast, easy connection and disconnection, bringing significant time and cost reductions. Furthermore, tightening the connection requires no additional tooling. RPC-SP connectors are therefore ideal for use where space is at a premium such as in many rack and plug-in applications. The product range comprises cable, panel and PCB connectors, adaptors to other coaxial connector series, airlines as well as test & measurement accessories such as RPC-SP calibration kits, test cables or measurement equipment (open – short – load).

Rosenberger coaxial jumpers have been designed using the many years of experience gained by Rosenberger engineers in this field. The unique knowledge of designing and manufacturing world-leading PIM testing equipment is directly reflected in the jumpers. Rosenberger jumpers have the industry-best PIM levels: -117 dBm / -160 dBc @ 2 x 20 W (typ. -120 dBm / -163 dBc @ 2 x 20 W). These excellent levels are guaranteed for every assembly that leaves the Rosenberger production facility.
