Reverse SMA / BNC / TNC

Rosenberger Longwipe-SMP subminiature coaxial connectors are suited to applications up to 6 GHz and enable axial tolerance compensation of ± 0.7 mm. Full and limited detent options are available as well as smoother bore/catchers mitt, enabling sliding contact with expanded guide-in range.

Rosenberger SMC subminiature coaxial connectors are for various applications up to 6 GHz. Based on a similar design to the SMB solution, the SMC’s screw-on locking mechanism provides a reliable connection for application in internal devices and cable assemblies. Please note: Rosenberger defines male – female according to the design of center contact.

The Rosenberger HPK system can achieve 275 A at 85 °C up to 1000 V. With their excellent vibration and current capacity performance the HPK connectors are well-suited to typical high-voltage electric vehicle applications such as the connection between battery, inverter and PDU. The range includes 1-, 2-, or 3-pole connectors which for maximum flexibility can be used with copper or aluminum cables in four different cable cross sections. Straight and angled cable couplers as well as corresponding headers are available, either with or without HVIL (high-voltage interlock).

Rosenberger’s comprehensive portfolio of cost-effective, high-quality and precision products enables a broad spectrum of industrial test & measurement applications for active or passive devices. While several types of network analyzers (NAs) have become increasingly important in the development of microwave circuits and systems in industrial measurement applications, vector network analyzers (VNAs) are particularly useful. This is due to their calibration capability and the ability to measure more parameters. Rosenberger develops and offers a wide range of metrology kits for a variety of standard and precision interfaces when performing calibration, verification and traceability, as well as gauges and gauge kits for vector network analyzers (VNAs).
