RosenbergerHSD®

Rosenberger’s new EBC® (Efficient Board Connector) series is the ideal 5G board-to-board and board-to-module RF interconnect solution for active MIMO (Multiple Input Multiple Output) antennas and radios. Outstanding performance, low cost design and high mechanical stability make EBC® the perfect future-proof product for 5G radio interconnections. For applications up to 8 GHz, EBC® connectors fulfill the challenging requirements caused by the exponential data volumes increases in future 5G networks. Essential characteristics include extremely small dimensions, radial and axial misalignments, different holding forces, minimum board-to-board distances, and fast and cost-effective assembly design. A key mechanical design feature is the locating side which is integrated in the bullet. One side has a smooth bore, while the other has a limited-detent design. The single PCB coupler provides a consistent footprint with preloaded outer contacts for ensuring contact optimization, the push/snap-on locking mechanism allows fast and easy disconnection.

The Rosenberger MTD® Connection System is an industry standard* Ethernet transmission system for optimized jacketed Twisted-Pair cables. Its excellent transmission and electrical performance, reduced weight, size and cost benefits have set new standards for 100 Mbps and 1 Gbps single connection Ethernet implementation in vehicles. Compared to other solutions currently available a key advantage of Rosenberger’s new connection system is the impedance-controlled transition area from cable to connector interface. Its small size in combination with several coding features allows multiple wire pairs to be placed in close proximity ensuring installation space is kept to a minimum. Furthermore, the honeycomb structure provides low crosstalk, good symmetry and can be extended modularly.

Rosenberger N coaxial screw-on connectors offer a high degree of weather protection and excellent intermodulation. Their mechanical stability and weather resistance make N connectors well-suited to outdoor applications such as mobile antennas.

Rosenberger provides a wide product range of solderless PCB connectors for challenging test & measure­ment demands and for frequencies up to 110 GHz. These PCB connectors can easily be assembled by using screws. Standard screws are included, optional screws for thicker PCBs are available on request.
