RosenbergerHSD® is a homogeneous impedance-controlled interconnect system which directly addresses the high-speed data, low-voltage requirements of real-time automotive industry applications. Extremely compact and durable this 100 Ohm fully shielded interconnect system utilizes shielded twisted quad cables and features mechanical keying and latching for high connection retention, as well as coding to avoid misuse. Furthermore, these precision manufactured RosenbergerHSD®SF variants are ideally suited for process-safe and fully automated assembly by harness makers, facilitating a significant reduction in costs. Its high data throughput performance while also preventing interference from crosstalk and external sources makes the RosenbergerHSD® cable and PCB connector system the perfect choice for LVDS cameras, USB connections and IEEE 1394 applications. In addition, it is well-suited to many other applications including those found in digital infotainment electronics and digital symmetrical networks – even radio base stations.

Rosenberger N coaxial screw-on connectors offer a high degree of weather protection and excellent intermodulation. Their mechanical stability and weather resistance make N connectors well-suited to outdoor applications such as mobile antennas.

Rosenberger SMC subminiature coaxial connectors are for various applications up to 6 GHz. Based on a similar design to the SMB solution, the SMC’s screw-on locking mechanism provides a reliable connection for application in internal devices and cable assemblies. Please note: Rosenberger defines male – female according to the design of center contact.

Rosenberger’s series VIA® (Variable Interface Adaptor) is designed for board-to-board and board-to-module RF interconnections up to 6 GHz. The innovative mechanical design features both limited detent and smooth bore interfaces integrated into the adaptor – one side of the bullet is responsible for limited detent, the other side for smooth bore. The unique catch mechanism inside the adaptor ensures secure, reliable connection. The Rosenberger VIA® covers all requirements for multiple connections and complex mobile communication solutions in remote radio heads (RRHs) as well as in various other applications.
