HVR®260

Rosenberger has expanded its product portfolio for 100BASE-T1 connections with AMEC Ethernet connectors. In technical cooperation with Delphi/APTIV, further cost-effective high-speed Ethernet solutions for the automotive market are being developed. These robust, compact connectors deliver the high performance necessary for a range of applications including autonomous driving, driver assistance, rear seat entertainment, and LVDS & camera systems. The Delphi and Rosenberger AMEC program is 100 % compatible, ensuring the customer has a fully approved second source.

Rosenberger WSMP®PCB connectors, bullets and cable assemblies are extremely compact and capable of handling frequencies up to 100 GHz. WSMP® connectors are about 45 % smaller than standard SMP connectors for allowing high packing density. Featuring a push-on coupling mechanism and enabling a minimum board-to-board distance of 3.05 mm, they are optimized for customer-specific footprints and layout recommendations.

Constantly increasing bandwidth requirements in all areas of communication and computing are placing ever greater demands on networking I/O equipment. Current edge-mount copper or fiber interfaces are at their limits even over the short distances on the PCB. Embedded parallel optics have become the solution of choice to meet these demands. High-performance routers, switches and computers have already been utilizing this technology for a decade. Parallel optic solutions are currently used in a wide range of applications: in links between nodes of supercomputers, switches in international Internet gateways as well as in data centers and central offices. Embedded opto-electrical modules and optical engines utilize parallel-optics transmitter and receiver arrays. For optimum signal integrity, thermal management, I/O consolidation and EMI/ESD, the opto-electrical modules are directly mounted close to the processors at the PCB. Parallel-optic links can complement electronic signalling in parallel lanes such as XAUI and PCIe. Using PRIZM® Light Turn®, it is possible to implement a passive plug connection between the opto-electrical modules and the fiber optic network.
