MXC®

Rosenberger’s comprehensive portfolio of cost-effective, high-quality and precision products enables a broad spectrum of industrial test & measurement applications for active or passive devices. While several types of network analyzers (NAs) have become increasingly important in the development of microwave circuits and systems in industrial measurement applications, vector network analyzers (VNAs) are particularly useful. This is due to their calibration capability and the ability to measure more parameters. Rosenberger develops and offers a wide range of metrology kits for a variety of standard and precision interfaces when performing calibration, verification and traceability, as well as gauges and gauge kits for vector network analyzers (VNAs).

Rosenberger snap-in Mini-Coax inserts for Metral-chassis card edge connections offer modular high packing densities due to their extremely small size. As well as Multiport Mini-Coax are available in multiple 2, 4, 6 and 8 channel variants. Further benefits include fast, reliable connection, high data transmission rates, and superior electrical and mechanical stability.

Rosenberger Rack Analyzers are designed to make PIM tests in production or test lab environments exceptionally modular, precise, and efficient. The budget-friendly broadband base unit concept offers maximum flexibility thanks to the option of connecting up to 11 filter units to one base unit. Integrated DTF measurement enables faster fault-finding by accurately pointing out the source of PIM. With the plug-and-play filter concept, intuitive software operation and easy-to-replace dust filters, it is possible to create a significant reduction in production downtime caused by changes in test frequencies or maintenance and servicing work.

Rosenberger RPC-N precision connectors – with screw-on locking mechanism – are designed for applications 50 Ω up to 18 GHz, 75 Ω up to 4 GHz. RPC-N 50 Ω are intermateable with standard N 50 Ω connectors, RPC-N 75 Ω are intermateable with standard N 75 Ω connectors. Rosenberger RPC-N 50 Ω and RPC-7 connector heads are interchangeable using the same bead type.
