RPC-3.50

The Rosenberger HPK system can achieve 275 A at 85 °C up to 1000 V. With their excellent vibration and current capacity performance the HPK connectors are well-suited to typical high-voltage electric vehicle applications such as the connection between battery, inverter and PDU. The range includes 1-, 2-, or 3-pole connectors which for maximum flexibility can be used with copper or aluminum cables in four different cable cross sections. Straight and angled cable couplers as well as corresponding headers are available, either with or without HVIL (high-voltage interlock).

The Rosenberger HVR®300 connector system not only provides a maximum current carrying capacity of 320 A, it takes up minimal space. It features a 2-pole angled coupler for shielded cables and a cable cross section of 70 mm² along with the corresponding header. A cross section of 50 mm² is available on request. The lever locking mechanism is secured with an additional slider (CPA – Connector Position Assurance) to prevent accidental unmating.
