Manyetik Olmayan Konektörler

Rosenberger RPC-2.40 connectors – high reliability and outstanding repeatability – are designed for precision test & measurement applications up to 50 GHz. With 50 Ω impedance and 2.40 mm outer conductor, they are intermateable with many other 2.40 mm series connectors such as APC-2.40, OS-50, HP-2.40 or RPC-1.85 and V connectors. A wide range of RPC-2.40 cable and PCB connectors, adaptors and interchangeable port connectors is available as well as test & measurement accessories. These include RPC-2.40 calibration kits, test cables and measurement equipment.

Rosenberger RPC-7 “hermaphroditic” connectors with 7 mm diameter at outer contact are designed for precision measurements up to 18 GHz and are suitable for semi-rigid cables and microwave components. Mating electrically with center and outer conductor by end-surface (butt) contact, the mechanical connection is designed as a counter-sinkable threaded socket. For total flexibility, these low reflection connectors are intermateable with all common 7 mm series connectors including APC-7, PC-7, GPC-7 or Precifix AA. Furthermore, RPC-7 and RPC-N connector heads are interchangeable using the same bead type. The wide product range comprises connectors and connector heads, adaptors, interchangeable port connectors, airlines as well as test & measurement accessories such as RPC-7 calibration and verification kits, test cables, attenuators or measurement equipment (open – short – load).

Rosenberger Longwipe-SMP subminiature coaxial connectors are suited to applications up to 6 GHz and enable axial tolerance compensation of ± 0.7 mm. Full and limited detent options are available as well as smoother bore/catchers mitt, enabling sliding contact with expanded guide-in range.
