MagCode®

The RosenbergerHPD® universal multicore datalink connection system is optimized for data transmission up to 10 Gbps. In addition to high data performance, the centrally positioned power lane offers a power reserve of up to 100 W / 5 A – in combination with the cable shield as the ground lane. Providing data and power to complex systems through a single interface delivers several benefits including reduced costs and installation footprint. This robust, fully shielded connector is ideally suited to harsh environmental conditions, such as automotive applications, where frequent high data transmission and ampacity is required. Combined with Rosenberger’s specially designed multicore cable, featuring an optimized layout for low attenuation, virtually interference- and crosstalk-free performance is assured.

Rosenberger RPC-2.40 connectors – high reliability and outstanding repeatability – are designed for precision test & measurement applications up to 50 GHz. With 50 Ω impedance and 2.40 mm outer conductor, they are intermateable with many other 2.40 mm series connectors such as APC-2.40, OS-50, HP-2.40 or RPC-1.85 and V connectors. A wide range of RPC-2.40 cable and PCB connectors, adaptors and interchangeable port connectors is available as well as test & measurement accessories. These include RPC-2.40 calibration kits, test cables and measurement equipment.

Rosenberger’s series VIA® (Variable Interface Adaptor) is designed for board-to-board and board-to-module RF interconnections up to 6 GHz. The innovative mechanical design features both limited detent and smooth bore interfaces integrated into the adaptor – one side of the bullet is responsible for limited detent, the other side for smooth bore. The unique catch mechanism inside the adaptor ensures secure, reliable connection. The Rosenberger VIA® covers all requirements for multiple connections and complex mobile communication solutions in remote radio heads (RRHs) as well as in various other applications.

PreCONNECT® DUODECIM is the perfect solution for all who still have conventional transceivers for duplex applications like 10/25/50 GBE and 8/16/32 GFC on both cabling sides in foreseeable time, but want to be prepared for the migration to MPO based parallel optics applications. Trunks and 19" panels can be further used for migration. The fiber optic cabling system PreCONNECT® DUODECIM promises investment security by optimal use of the trunks for duplex applications and MPO based parallel optical applications. The perfectly matched modular individual components are quick and easy to install thanks to the factory-fabricated Plug & Play system.
