Connectors – Industry Leading Performance

Complementing its standard HV connector portfolio, Rosenberger develops and manufactures customer-specific high-voltage components for electric and hybrid vehicles. These enable the lowest possible transition resistances, ensuring long-term low-loss performance and reliability in critical electrical systems such as those for battery charging, cell management, heating, and air conditioning. From concept to final delivery, Rosenberger high voltage custom components are the perfect fit every time. Using its component toolkit, including PDUs, Y-splitters, Busbars and Cell Modules, Rosenberger can develop and manufacture a wide array of tailor-made solutions. These are designed and configured precisely to the relevant vehicle architecture, allowing ideal combinations of the various fuses, relays and other passive and active components required. Power Distribution Units (PDU) Power distribution units (PDU) for vehicles have multiple power input and outputs and use all kinds of connectors, fuses, and relays. In these cases, the PDU generally forms the central link between the vehicle power electronics and batteries, electric motors, and other ancillary units. Y-Splitters Y-splitters are used to distribute the power from one cable harness to two or more units, e.g., between a DC/DC converter and an electric air-conditioning unit. Rosenberger can design Y-splitters for applications with and without shielding for cable cross sections from 4 mm² to 95 mm² in collaboration with the customer. Cell Module Connectors The Rosenberger HV portfolio also includes cell module connectors. These connectors are required to link battery modules within a battery pack. For typical battery applications, multiple custom-designed battery connection points are required. Based on the robust pressure contact system, Rosenberger offers cell module connectors without flexing parts in the contact area. Systems from 100 to 350 A are available. Different assembly directions, coding variants as well as cross sections can be implemented according to customer-specific requirements.

Rosenberger coaxial jumpers have been designed using the many years of experience gained by Rosenberger engineers in this field. The unique knowledge of designing and manufacturing world-leading PIM testing equipment is directly reflected in the jumpers. Rosenberger jumpers have the industry-best PIM levels: -117 dBm / -160 dBc @ 2 x 20 W (typ. -120 dBm / -163 dBc @ 2 x 20 W). These excellent levels are guaranteed for every assembly that leaves the Rosenberger production facility.

When it comes to ensuring straightforward connector and cable assembly, Rosenberger has got it covered. Rosenberger offers a wide range of specialist tools and accessories including those for crimping and handling crimp inserts, as well as torque wrenches and various extraction tools and accessories. To select tools for specific connectors or applications, please see Rosenberger data sheets and / or assembly instructions.

PerCONNECT® EcoFlex’IT™ is the next step on from PerCONNECT®, with active components and an innovative overall concept which focuses on efficient and flexible and find its application in new and existing network installations. A central element in this complete system is the Active Consolidation Point (ACP), which is integrated in the backbone with fiber optics and is distributed in the close tertiary area (max. 20 m) on copper trunks or patch cables. PerCONNECT® EcoFlex’IT™ is a ring configuration which is redundantly designed as an FTTACP (fiber to the active consolidation point). By installing the ACPs in raised floors, ceilings or walls, the cabling system can be integrated in any work environment without the need for additional space, can be taken out again at any time, is easy to move and is flexibly upgradeable.
