AQ6376 Three Micron Optical Spectrum Analyzer 1500 - 3400 nm

AQ7933 is application software to display and analyze the waveform data measured on a YOKOGAWA OTDR and create and output reports of analysis results on a PC. It displays up to 20 waveforms at the same time and creates a work report in 3 steps. The software integrates applications that the previous software doesn’t have, such as the OTDR remote controller, and assists field engineers in their waveform confirmation work.

AQ7932 is application software that performs analysis of trace data from the OTDR on a PC, and conveniently creates professional reports. The built-in report creation wizard function makes this task simple, quick and easy. Display up to eight traces on screen, and perform a variety of analyses including multi-trace analysis and differential trace analysis for comparing recent waveforms with old ones, and use the 2 way trace analysis function for analyzing average values of data measured from both directions in the optical fiber.

The AQ2200-651 Signal Generator module reduces the complexity and cost of 10G optical transceiver testing by combining Signal Generation functions into the same mainframe that provides bus and power control while performing BERT and Optical testing. This allows a single programming interface to control all aspects of the transceiver test, simplifying test setup, decreasing test time and increasing productivity. The wiring complexity and test bench size are reduced by replacing up to 5 Signal Generators with a single module.
