Optical Fiber Identifier FID-30R/31R

RS03 - 80 is a tool for removing the optical fiber coating for clad diameter 80 μm. By heating and softening the coating, the coating can be easily removed. By using an optional spacer, a short lead (3 mm to 5 mm) is also possible. Fiber holder is compatible with FH - 100 series and FH - 40 series. Furthermore,equipped with new features such as large capacity battery for 600 stripping cycles, 6 times larger than conventional stripper, and wireless link with smartphones for operational parameters adjustment.

The 90R16 is a mass fusion splicer capable of splicing up to 16 fiber ribbon cables simultaneously. In previous mass fusion splicer models, the v-grooves could become dirty over time due to debris and glass deposits from splicing accumulating in the v-grooves. Which in turn, could lead to fibre offsets and high losses if they were not regularly cleaned which added to the overall process time. The 90R16 comes with a first of its kind, innovative user replaceable V-groove assembly which makes this issue a thing of the past and is supplied as standard equipment with the 90R16 kit. This new V-groove assembly can be quickly and easily fitted in the field, minimizing downtime and maximising productivity. In addition, the new V-groove design enables splicing of both conventional type 12-fiber encapsulated ribbon and SWR (Spider Web Ribbon) whilst also accommodating 250um and 200um pitch fibers. The 90R16 can also splice single fibers if required. also making use of Active Blade Management Technology, which now can connect to two CT50 cleavers simultaneously. Features

SS03 have three holes. The smallest hole is for stripping 250 um cable down to glass fiber. The second hole is for stripping 900 um buffer coating down to 250 um buffer coating. The biggest hole is for stripping 2-3mm fiber jacket down to 900 um buffer coating.

The CleaveMeter 3DTM is a phase-shifting Michelson interferometer for non-contact end-face inspection of cleaved and polished optical fibers with cladding diameters up to 1200 μm. Designed for both production and research applications, this comprehensive fiber optic testing system combines full resolution, three-dimensional surface topography reconstruction and mapping with automated, operator independent measurements of cleave angle and surface flatness in a small, lightweight benchtop unit.
