RPC-2.92

MultiMag connectors are designed for small and compact applications in tight spaces. These include, for example, MultiMag 6 for applications such as USB connection and MultiMag 15 for general power and data transmission. These innovative magnetic self-mating connectors automatically discover connections and prevent tearing. They're ideal for products and environments where frequent connection and disconnection is a prerequisite, from medical devices and industrial automation to drones, robots, smart watches and data glasses.

Rosenberger WSMP®PCB connectors, bullets and cable assemblies are extremely compact and capable of handling frequencies up to 100 GHz. WSMP® connectors are about 45 % smaller than standard SMP connectors for allowing high packing density. Featuring a push-on coupling mechanism and enabling a minimum board-to-board distance of 3.05 mm, they are optimized for customer-specific footprints and layout recommendations.

The Rosenberger HPK system can achieve 275 A at 85 °C up to 1000 V. With their excellent vibration and current capacity performance the HPK connectors are well-suited to typical high-voltage electric vehicle applications such as the connection between battery, inverter and PDU. The range includes 1-, 2-, or 3-pole connectors which for maximum flexibility can be used with copper or aluminum cables in four different cable cross sections. Straight and angled cable couplers as well as corresponding headers are available, either with or without HVIL (high-voltage interlock).
