Multi-Power

Rosenberger RPC-1.00 precision connectors – with 50 Ω impedance and 1.00 mm outer diameter – can be used for challenging test & measurement applications up to 110 GHz. They are characterized by excellent technical data over the full frequency range, meet the highest levels of reliability and repeatability of performance, and are intermateable with common 1.00 mm connectors. The standard portfolio covers flexible and semi-rigid cable assemblies, adaptors and PCB connectors. Waveguide-to-coaxial adaptors and gauge kits are also available. Customer-specific cable assembly solutions with or without armouring available on request.

Rosenberger’s new RPC-1.35* precision connector series meets the growing demand for precision, high-performance RF-connections up to 90 GHz. The range addresses the expanding market for 5G, industrial sensors in the E-Band, millimeter wave sensors for self-driving vehicles, WLAN IEEE 802.11ax and 802.11ay. RPC-1.35 connectors offer a highly robust mechanical design, minimum 3000 mating cycles, high connector repeatability, and maximum return loss values – ideal for ensuring RF measurements in the E-Band without delays. The product portfolio covers semi-rigid and flexible cable assemblies, PCB connectors, test PCBs, cable connectors, in-series and inter-series adaptors, test ports, floating and waveguide-to-coaxial adaptors as well as gauge and calibration kits. *A working group, comprising PTB (Physikalisch Technische Bundesanstalt), Rosenberger, Rohde & Schwarz and Spinner, designed the new 1.35 mm connector to close the gap between 1.85 mm and 1.00 mm connectors. The interface standardization is in progress.

Rosenberger HVR®50 connectors are available in straight and angled variants. The additional slide locking mechanism (CPA – Connector Position Assurance) prevents accidental disconnection. Despite their small size these connectors achieve a current capacity of approximately 60 A at 85 °C. HVR®50 connectors are mainly used in ancillary units such as electrical heating systems, air-conditioning units, DC/DC converters, and for charging batteries.

The Rosenberger Spring Loaded Coax System is designed to make quick, reliable and low abrasion PCB con­nections – up to 18 GHz (SMA interface) or up to 40 GHz (RPC-2.92 interface) – to single-layer or multi-layer printed circuit boards with the microwave layer on top.
